58-77 Volkswagen Beetle Digital Instruments

Read more...
$736.25 Excl. tax
Delivery time: Delivery times can range from 12 weeks on VHX kits to16 weeks for HDX, RTX & GRFX kits.

58-77 Volkswagen Beetle Digital Instruments

Dakota Digital Series III instrument systems offer the latest technologies and features for your custom vehicle. High brightness vacuum fluorescent displays provide a lifetime of trouble free use while offering increased accuracy and features!

Full 6 Gauge Instrument System includes Billet Aluminum bezels for 1958-77 Volkswagen Beetle models.

Head temperature can be monitored within the VFD3 system with the use of a BIM-12-1

Digital Gauges

Speedometer
·0 -255 MPH (optional metric version 0- 255 km/h)

Tachometer
·0- 17,500 RPM

Oil Pressure
·0- 99 psi

Oil Temperature
·0- 300ºF (optional metric version 0- 150ºC)

Fuel Level
·0- 99%

Voltmeter
·8- 17 VDC

Standard Colors
·Blue or Teal

Digital Message Centers


Standard Displays
·Odometer (One time user settable, Million Mile)
·Dual (A/B) Trip Meter (0- 9,999.9)

Performance Meters
·0- 60 MPH Timer (0- 100 kmh)
·1/4 mile time
·1/4 mile end speed (trap speed)
·High speed recall
·High RPM recall

Gauges
·Speedometer (0- 255 MPH/kmh) opposite scale of main speedometer.

Built-in Indicators

Indicators
·Turn Signals (Left/ Right)
·High Beam
·Check Engine
·Parking Brake
·Cruise Control (On/ On & Engaged when vehicle is equipped)
·Gear Position (Optional GSS-3000 sensor required)
·4 x 4 (When vehicle is equipped)
·Wait to Start (When vehicle is equipped)
 **Not all OEM indicator lamp functions will be replaced.
  • If additional indicators are desired within the new instrument system, consider repurposing any unused indicators to suit your application.

Included Sensors
sVFD3 Specs VW (Bottom)

Water Temperature
1/8" NPT, ground isolated sensor with a 10 ft harness.

Oil Pressure
1/8" NPT solid state sensor with a 10 ft harness.

Cable Driven Speed Sensor/ Generator
·Attaches to VW style speedometer cables with a 10 ft harness.

Bushings
Each kit comes with 1/8" to 1/4", 3/8" and 1/2" NPT bushings along with bushings for 12mm and 16mm x 1.5 threads.

Calibration

Pushbutton
Dakota Digital instruments are programmed and operated by the push of a button. Simply mount the included pushbuttons supplied with your gauges in a convenient and easily accessible location. These buttons are used to calibrate your speedometer, set the cylinder count and the fuel level gauge. Once properly configured these same buttons are used to access the wealth of information located in the Digital Message Centers.

VFD3-VW-B, VFD3-VW-T
