Borgeson - Power Steering Conversion Box - 65-67 Mustang; 60-65 Falcon - 800110

Home / Power Steering Conversion Box - 65-67 Mustang; 60-65 Falcon - 800110

Borgeson power steering conversion box for 1965-1967 Ford Mustangs with 1" sector shaft.

Borgeson Power Steering Conversion Box - 65-67 Mustang; 60-65 Falcon - 800110

$518.81 Excl. tax

Delivery time: Typically ships within 7-10 business days

Brand:

Borgeson

Information

Borgeson power steering conversion box for 1965-1967 Ford Mustangs with 1" sector shaft. Modern integral power steering conversion box with a quick 14:1 ratio and firm modern feel. Steering column modifications required for installation, see product instructions for more info. All Borgeson power steering boxes are assembled and tested in the USA from globally sourced components and have a 3 year warranty.

NOTE: 1967 Used 1" & 1-1/8" pitman shafts measure first!

NOTE: This box fits 60-65 Falcons with 1" Sector Shaft.

NOTE: Will not fit with factory Z-Bar clutch linkage.

800110 SPECIFICATIONS:

800110 Installation Drawing

Input Shaft: 11/16"-36 Spline

Pitman Shaft: 1" Ford with 32 Splines and 4 Master Splines

Pressure Port: 16mm X 1.5 Flare (Located closest to engine)

Return Port: 16mm X 1.5 Flare (Located closest to input shaft)

Maximum Pressure: 1450 PSI Maximum Operating Pressure, 1100-1250 Optimal

Flow Rate: 2.0-2.5 GPM Flow Rate Recommended
