Kwik Performance - Corvette (97-13) LS Alt Only Bracket - K10192

Wide-Mount Alternator Only for LS engines with Corvette (1997-2013) crank pulley and water pump spacing.*

This bracket mimics the factory OEM Corvette Alt/PS configuration in an Alt Only offering.

• Corvette Alternators (1997-2013)
• Truck Alternators (1999-2013)
• Camaro/GTO Alternators (1998-2002)
• Camaro Alternators (2010-15)
• DOES NOT fit Cadillac CTS-V / LSA Alternators

• Bracket made of 6061-T6 aircraft grade aluminum (brushed satin finish)
• All necessary spacers and zinc coated fasteners

• GM LS Gen 3 or 4 engine with Corvette (1997-2013) harmonic balancer and water pump (or equivalent)*
• Six-rib belt, See our included installation instructions for suggested lengths and Gates part numbers.
  • Alternator rating and PS pulley diameters can change suggested lengths.
  • Always check tensioner marks for correct fitment.

• Most Chevrolet “crate” engines
• Cadillac CTS-V (2006-07, non-supercharged)
• Pontiac G8 (2009)
• Chevrolet SS (2013-17)
• Caprice PPV (2009-17)
• Holden Commodore (2009-17)

• Properly engineered using OEM reference drawings
• Computer tested with FEA (finite element analysis) software
• Field tested on shop test engines and in real-world test vehicles
• Backed by a no-hassle warranty and return policy
• Tech support before, during and after the sale

Teams up perfectly with our Wide Mount AC bracket K10470

Works with your OEM tensioner (mounted on water pump)

• Corvette (1999-2013)
• Cadillac CTS-V (2006-07, non-supercharged)
• Pontiac G8 (2009)
• Chevrolet SS (2013-17)
• Caprice PPV (2009-17)
• Holden Commodore (2009-17)

How to determine which Chevy LS balancer you have
